VEGA 320/3750-7500 FPD IP67
127862
€ 165,62
price VAT included
-
+
Features
Rated Voltage
100 V
110...127 V
220...240 V
277 V
Constant Current
Current
3750 mA
220-240 V = Output power
232,5 W
Current
4000 mA
220-240 V = Output power
248 W
Current
4500 mA
220-240 V = Output power
280 W
Current
5000 mA
220-240 V = Output power
310 W
Current
5500 mA
220-240 V = Output power
320 W
Current
5750 mA
220-240 V = Output power
320 W
Current
6000 mA
220-240 V = Output power
320 W
Current
6400 mA
220-240 V = Output power
320 W
Current
7000 mA
220-240 V = Output power
320 W
Current
7500 mA
220-240 V = Output power
320 W
Dimming:
1-10V - 0-10V
MIDNIGHT Function
CLO Function
FULL PROGRAMMABLE
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV >60/< />
WIDE RANGE INPUT VOLTAGE
6/10 kV DM/CM SURGE Input Protection
Approvals:
ENEC
UL (other than class 2)
RCM
CE
Plastic case:
IP 67
Size:
231 x 42 x 98 mm
last update:
5/21/2024
