R-LED 80/700 DALI SLIM
127936
€ 63,44
price VAT included
-
+
Features
Rated Voltage
220...240 V
Constant Current
Current
AOC via cables (ADJ. OUT. CURRENT)
Current
LEDset / RESISTOR
Current
350 mA
220-240 V = Output power
77 W
Current
360 mA
220-240 V = Output power
79,2 W
Current
370 mA
220-240 V = Output power
80 W
Current
375 mA
220-240 V = Output power
80 W
Current
380 mA
220-240 V = Output power
80 W
Current
390 mA
220-240 V = Output power
80 W
Current
400 mA
220-240 V = Output power
80 W
Current
410 mA
220-240 V = Output power
80 W
Current
420 mA
220-240 V = Output power
80 W
Current
425 mA
220-240 V = Output power
80 W
Current
430 mA
220-240 V = Output power
80 W
Current
440 mA
220-240 V = Output power
80 W
Current
450 mA
220-240 V = Output power
80 W
Current
460 mA
220-240 V = Output power
80 W
Current
470 mA
220-240 V = Output power
80 W
Current
475 mA
220-240 V = Output power
80 W
Current
480 mA
220-240 V = Output power
80 W
Current
485 mA
220-240 V = Output power
80 W
Current
490 mA
220-240 V = Output power
80 W
Current
500 mA
220-240 V = Output power
80 W
Current
510 mA
220-240 V = Output power
80 W
Current
520 mA
220-240 V = Output power
80 W
Current
525 mA
220-240 V = Output power
80 W
Current
535 mA
220-240 V = Output power
80 W
Current
540 mA
220-240 V = Output power
80 W
Current
550 mA
220-240 V = Output power
80 W
Current
560 mA
220-240 V = Output power
80 W
Current
575 mA
220-240 V = Output power
80 W
Current
580 mA
220-240 V = Output power
80 W
Current
600 mA
220-240 V = Output power
80 W
Current
610 mA
220-240 V = Output power
80 W
Current
625 mA
220-240 V = Output power
80 W
Current
640 mA
220-240 V = Output power
80 W
Current
650 mA
220-240 V = Output power
80 W
Current
670 mA
220-240 V = Output power
80 W
Current
675 mA
220-240 V = Output power
80 W
Current
700 mA
220-240 V = Output power
80 W
Dimming:
DALI-2 (also DALI-1)
PUSH (on the Mains)
CLO Function
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
NOT SELV (>120V)
DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-Warm
EXTERNAL NTC INPUT
Suitable for AUTOMATIC WIRING MACHINE
Approvals:
ENEC
RCM
CE
EAC
UKCA
Plastic case:
Slim
for Built-in
Size:
280 x 21 x 30 mm
last update:
5/2/2022
Product info
Country of production:
China
EAN:
8010703393967
HS code:
85044083
