MP 32 TC

122172

122172
€ 31,77
price VAT included

-
+

Features

Rated Voltage
110...127 V
220...240 V
Constant Current
Current
250 mA
220-240 V = Output power
12 W
110-127 V =
12 W
Current
300 mA
220-240 V = Output power
14 W
110-127 V =
14 W
Current
350 mA
220-240 V = Output power
17 W
110-127 V =
17 W
Current
400 mA
220-240 V = Output power
19 W
110-127 V =
19 W
Current
450 mA
220-240 V = Output power
21 W
110-127 V =
21 W
Current
500 mA
220-240 V = Output power
24 W
110-127 V =
24 W
Current
550 mA
220-240 V = Output power
25 W
110-127 V =
25 W
Current
600 mA
220-240 V = Output power
28 W
110-127 V =
28 W
Current
650 mA
220-240 V = Output power
30 W
110-127 V =
30 W
Current
700 mA
220-240 V = Output power
32 W
110-127 V =
32 W
Current
750 mA
220-240 V = Output power
32 W
110-127 V =
32 W
Current
800 mA
220-240 V = Output power
32 W
110-127 V =
32 W
Current
850 mA
220-240 V = Output power
32 W
110-127 V =
32 W
Current
900 mA
220-240 V = Output power
33 W
110-127 V =
33 W
Constant Voltage (LED STRIP)
Current
12 V
220-240 V = Output power
11 W
110-127 V =
11 W
Current
24 V
220-240 V = Output power
20 W
110-127 V =
20 W
Dimming:
NOT DIMMABLE
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV < />
WIDE RANGE INPUT VOLTAGE
LOOPING on PRIMARY SIDE
Approvals:
KEMAKEUR
ENEC
RCM
CE
EAC
UKCA
Plastic case:
Square
IP 20 (Independent Use)
Minimum cut-out hole diameter:
88 mm
Size:
169 x 35 x 83 mm
last update:
10/14/2022
Output voltage (min/max)
250 mA
2...47
300 mA
2...47
350 mA
2...47
400 mA
2...46
450 mA
2...47
500 mA
2...47
550 mA
2...47
600 mA
2...47
650 mA
2...47
700 mA
2...47
750 mA
2...42
800 mA
2...40
850 mA
2...37,5
900 mA
2...36,5
